Brake Assembly

Brake Assembly 15" – Reduced Envelope Brakes (pages 8–9)

For Model: ES-150-6D Steer Axle Reduced Envelope Brake

Item No. Part Name Qty. Part No. Notes

1 Camshaft Retainer Snap Ring 1 804017

2 Camshaft Shim Washer AR 23570 .030"

3 Camshaft Shim Washer AR 35428 .060"

4 Slack Adjuster Inner Washer 1 43943

5 Grease

Seal 2 79903

6 Camshaft Bushing 2 1000035

7 Camshaft Bracket Assembly 1 Varies See 16.5 ES Camshafts

8 Capscrew 4 38540 Brake Mounting

9 Lockwasher 4 90414 Brake Mounting

10 Spider & Pin Assembly w/Studs (see page 94) 2 816072/3 LH/RH

Spider & Pin Assembly w/o Studs (see page 94) 2 816806/7 LH/RH

11 Shoe (#816077) & Lining Assembly 2 816417 EES-301

Shoe (#816077 & Lining Assembly 2 816416 EES-201

12 Cam Washer 1 806380

13 Camshaft (see page 24) 1 Varies See 16.5 ES Camshafts

14 Retaining Spring 2 809513 Brake Shoe

15 Return Spring 2 817017 Red Spring

16 Roller 2 806234

17 Roller Retainer 2 808058

Note: The ES-150-6D uses special Camshaft Bracket and Standard ES Camshafts.
